    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy

    Ask Lasest Price
    Price : USD10,000-100,000/SET
    Brand Name : Jingtan
    Certification : CE
    Delivery Time : 60 days
    Payment Terms : L/C/T/T
    Supply Ability : 10pcs/month
    • Product Details
    • Company Profile

    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy

    Products Description
    Bottom discharge graphitization furnace Usage:
    Mainly used for vacuum sintering of special composite materials or cemented carbide, copper tungsten alloy, titanium alloy
    and other alloy materials.

    Characteristics:

    It is welded by flange and cylinder group, and welded by various types of steel and steel plate to reinforce the load-bearing frame used to place the furnace body.
    Adopts double butterfly water inter layer structure, furnace bottom after lifting through electric speed reducer reducer by synchronous bearing flexible drive, driven by electric screw bracket will be stable furnace bottom rising or falling, avoid graphite crucible in the process of rising and falling damage, lifting mechanism is equipped with upper and lower limit switch, furnace bottom fall in place after taking work carried out by production personnel.
    Automatic can be set manually according to the user process requirements and equipment requirements, no manual switch, temperature control precision is accurate, easy to operate.

    maximum service temperature
    3000℃
    Working Temperature
    Normal Temperature -3000℃
    Heating Rate
    15℃/min
    10℃/min
    8℃/min
    temperature control precision
    ±2℃
    Measurement method
    1000-3200℃ use Bi color infrared instrument
    Vacuum degree
    6.67*10-2Pa
    Furnace atmosphere
    Ar or Vacuum
    Feeding and discharging mode
    Bottom loading is adopted
    Specification
    Φ800*1600mm
    Φ1000*2000mm
    Φ1200*2500mm
    Power
    400kw
    500kw
    600kw
    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy

    Advantage 1:

    The lower discharging graphitization furnace is suitable for processing and graphitization of large products, which greatly improves the convenience of materials in and out.
    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy

    Advantage 2:

    Suitable for high-temperature treatment of materials ( sintering,graphitization, purification, etc.) under the protection of vacuum or atmosphere.
    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy
    Our company philosoph:
    We are not your supplier,but your parter and supply the whole thermal treatment furnace solutions with strong R&D research team,stable supply chain with 14+ years experience under the strict ISO9001:2015 quality management system.
    The State Intellectual Property Office of the People's Republic of China (SIPO), in accordance with the Patent Law of the People's Republic of China, examined and granted our patent rights:
    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy

    Patent for high temperature graphitization furnace:

    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy

    Patent for high temperature vacuum hot pressure furnace:

    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy

    Patent for high temperature continuous furifing graphitization furnace:

    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy

    Patent for carbonization sintering furnace:

    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy

    Patent for bottom discharge graphitization furnace:

    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy

    Patent for carbon fiber continuous furnace

    Production process
    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy

    Customer Photos
    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy
    Our logistics system is all around the world.
    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy
    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy
    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy
    Customer cooperation cases:
    3000 Degree Bottom Discharge Graphitization Furnace For Cemented Carbide / Copper Tungsten Alloy
    FAQ

    Are you a factory or trading company?

    Q: Are you a factory or trading company?
    A:Yes,we are China leading high-temperature vacuum furnace manufacturer 14+years,granted with many patent certifications in the domestic market.

    Do you have customization or OEM service?

    Q: Do you have customization or OEM service??
    A:Yes,we have powerful R&D team and high-tech equipment.So we can not only supply the regular model,but also the customizable furnace as the repuirment of our clients.

    What's your advantages?

    Q:What's your advantages?
    A:Quick response to your enquiry
    High quality control
    Stable supply chain in the domestic maket
    Timely delivery
    Excellent after-sales service,we can dispatch our engineer to the customer city for installation and debugging.
