    Induction Type Vacuum Continuous Graphitization Furnace 3000C For Carbon Structural Parts

    Ask Lasest Price
    Price : USD8,000-60,000/SET
    Brand Name : Jingtan
    Certification : CE
    Delivery Time : 60 days
    Payment Terms : L/C/T/T
    Supply Ability : 10pcs/month
    • Product Details
    • Company Profile

    Induction Type Vacuum Continuous Graphitization Furnace 3000C For Carbon Structural Parts

    Products Description
    Continuous graphitization furnaces:
    Graphitization furnace is a high-performance intelligent heating furnace introduced by our engineering and technical personnel to digest and absorb foreign temperature measurement, temperature control technology, intelligence, new material technology and furnace design technology.
    Suitable for high temperature treatment of materials (carbonization, graphitization, high temperature degreasing, impurity removal, etc.) under vacuum or gas protection.

    Ultimate Temperature
    ≤ 3200℃
    Common Temperature
    Normal Temperature - 3000℃
    High Temperature Zone Volume(mm)
    Φ100X150 φ200X300 φ300X500
    Working atmosphere in furnace
    Vacuum,hydrogen,nitrogen,inert gases,etc
    Temperature Uniformity
    ≤±10℃
    Temperature Measurement
    Far infrared optical temperature measurement (double connector automatic switch)
    Temperature Measurement accuracy
    0.2~0.75%
    Temperature Control Accuracy
    ±1℃
    Temperature Control
    Program control and manual control
    Limit Heating Rate
    80℃/ min (empty furnace, depending on the volume of high temperature zone and furnace structure)
    Power Supply
    IGBT control, thyristor control

    Application:

    Continuous graphitization furnaces are used for high temperature treatment and graphitization of carbon structural parts (products), c/c composite products, carbon fiber products, sintered graphitization of carbon fiber filaments and other materials that can be sintered and melted in a carbon environment.
    Induction Type Vacuum Continuous Graphitization Furnace 3000C For Carbon Structural Parts
    Induction Type Vacuum Continuous Graphitization Furnace 3000C For Carbon Structural Parts
    Application:
    Used for high temperature treatment and graphitization of carbon structural parts (products), c/c composite products, carbon
    fiber products, sintered graphitization of carbon fiber filaments
    and other materials that can be sintered and melted in a carbon
    environment.

    Characteristics:

    ● Reach the limit temperature of 3200℃, the common temperature of 3000℃ high temperature furnace, meet the sintering and graphitization of various materials.
    ● The digital display intelligent temperature control system, automatic, high precision to complete the temperature control process, the system can be according to the given warming curve warming, and can store 40 sections of a total of 200
    ● Adopt internal circulation pure water cooling system; Digital flow monitoring system.
    ● Comprehensive PLC water, electricity, gas automatic control and protection system.
