High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified

Hunan Jingtan Automation Equipment Co., LTD.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified from wholesalers

    Buy cheap High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified from wholesalers
    • Buy cheap High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified from wholesalers

    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified

    Ask Lasest Price
    Price : USD8,000-60,000/SET
    Brand Name : Jingtan
    Certification : CE
    Delivery Time : 60 days
    Payment Terms : L/C/T/T
    Supply Ability : 10pcs/month
    • Product Details
    • Company Profile

    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified

    Products Description
    1. Adopt foreign thermal insulation material and furnace structure, using temperature up to 3000℃.
    2. When carbon fiber wire is graphitized, the wire enters from one end and leaves from the other end, and the production efficiency reaches the standard level.
    3. Vertical temperature measurement is adopted.
    4. The placement of the temperature sensor does not affect cable routing.
    5. Used for the graphitization of phosphorus sheet graphite or carbon powder, adopting push-boat mode, continuous production, good production efficiency, energy saving.
    6. Using digital display intelligent temperature control system, automatic precision to complete the temperature measurement and temperature control process, the system can be heated according to the given temperature curve, and can store 20 pieces a total of 400 sections different process heating curve.
    7. Comprehensive PLC water, electricity, gas automatic control and protection system control cabinet and furnace body connection cable can be as long as 20m, and remote control in equipment.
    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified

    Product Usage

    (1) For high temperature graphitization and carbonization of carbon fiber.
    (2) other materials that can be sintered and purified in the carbon environment.
    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified

    Product Advantage

    High-performance intelligent ultra-high temperature equipment with strong support of domestic scientific research institutes and universities. The operating temperature of the equipment can reach 3000℃.
    Model
    JT-TWL-35
    JT-TWL-137
    JT-TWL-282
    JT-TWL-602
    JT-TWL-1000
    Max. Operating Temperature
    Normal Temperature 3000℃
    Chamber Size (mm)
    φ30*500
    φ50*700
    φ60*1000
    φ80*1200
    φ100*2000
    Working Atmosphere
    in the Furnace
    Vacuum, hydrogen, nitrogen, inert gases, etc
    Temperature Uniformitity
    ≤±10℃
    Temperature Measurement
    Far infrared optical temperature measurement
    Temperature
    Measurement Accuracy
    0.2-0.75%
    Temperature
    Measuring Range
    1000-3000 or 900-3500℃
    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified
    Qualification and Patents

    Our company philosoph:
    We are not your supplier,but your parter and supply the whole thermal treatment furnace solutions with strong R&D research team,stable supply chain with 14+ years experience under the strict ISO9001:2015 quality management system.

    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified
    The State Intellectual Property Office of the People's Republic of China (SIPO), in accordance with the Patent Law of the People's Republic of China, examined and granted our patent rights:
    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified

    Patent for carbonization sintering furnace
    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified

    Patent for bottom discharge graphitization furnace:
    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified

    Patent for carbon fiber continuous furnace
    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified

    Patent for high temperature graphitization furnace
    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified

    Patent for high temperature vacuum hot pressure furnace
    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified

    Patent for high temperature continuous furifing graphitization furnace
    Production process
    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified
    Customer Photoes
    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified
    Logistics System All Around the World.
    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified
    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified
    Customer Cooperation Cases
    High Temperature Intelligent Vacuum Induction Furnace Remote Control CE ISO Certified
    FAQ

    Are you a factory or trading company?

    Q: Are you a factory or trading company?
    A:Yes,we are China leading high-temperature vacuum furnace manufacturer 14+years,granted with many patent certifications in the domestic market.

    Do you have customization or OEM service?

    Q: Do you have customization or OEM service??
    A:Yes,we have powerful R&D team and high-tech equipment.So we can not only supply the regular model,but also the customizable furnace as the repuirment of our clients.

    What's your advantages?

    Q:What's your advantages?
    A:Quick response to your enquiry
    High quality control
    Stable supply chain in the domestic maket
    Timely delivery
    Excellent after-sales service,we can dispatch our engineer to the customer city for installation and debugging.
